NOTE: CC BEC PRO should never be operated in series or parallel with another BEC or backup receiver pack connected to the RX/Servo side of the circuit.
Specs:
- Max load: 20A peak
Max continuous current**
16 volts input = 15 amps
24 volts input = 13 amps
32 volts input = 11 amps
40 volts input = 9 amps
48 volts input = 8 amps - Volts: Cars: 6S LiPo / Airplanes: 10S LiPo / Helicopters (with disabled brake): 12S
- Adjustable output: 4.8-12.5V
- Size: 43 x 33 x 24 mm
- Weight: 29 g
**Ratings are determined with a 5mph airflow on the BEC.
